Hastelloy C22 C2000 B2 B3 Rod Wire Manufacturers in India, Hastelloy C22 C2000 B2 B3 Rod Wires Price, SS 2 Price per kg, Hastelloy C22 C2000 B2 B3 Rod Wire 2 suppliers, Hastelloy C22 C2000 B2 B3 Rod Wires Price, Hastelloy C22 C2000 B2 B3 Rod Wire Suppliers in UAE, Hastelloy C22 C2000 B2 B3 Rod Wire Suppliers UK, Hastelloy C22 C2000 B2 B3 Rod Wire Suppliers in Saudi Arabia, Hastelloy C22 C2000 B2 B3 Rod Wire Suppliers in Qatar, Hastelloy C22 C2000 B2 B3 Rod Wire Suppliers Australia.
Hastelloy C22 C2000 B2 B3 Rod Wire is known for its exceptional resistance to a wide range of chemical environments. These alloys are nickel-chromium-molybdenum-based materials designed to withstand severe corrosion. Hastelloy C22 C2000 B2 B3 Rod Wire provides outstanding protection against oxidizing and reducing agents, making them ideal for chemical and marine industries. Their superior performance in aggressive media such as hydrochloric acid and sulfuric acid ensures long service life. Hastelloy C22 C2000 B2 B3 Rod Wire offers excellent strength and stability across varying temperatures.
The Hastelloy C22 C2000 B2 B3 Rod Wire is widely utilized in chemical process equipment due to its superb corrosion resistance. These materials resist pitting, crevice corrosion, and stress corrosion cracking in both oxidizing and reducing conditions. Hastelloy C22 C2000 B2 B3 Rod Wire retains its mechanical properties even in hot contaminated environments. They are often used in reactors, heat exchangers, and evaporators exposed to harsh chemicals. The outstanding durability of Hastelloy C22 C2000 B2 B3 Rod Wire makes it suitable for critical industrial operations.
Hastelloy C22 C2000 B2 B3 Rod Wire offers excellent weldability and formability, allowing easy fabrication into complex components. They can be welded using standard techniques without compromising corrosion resistance. These rods and wires are often used in aerospace, pharmaceuticals, and pollution control systems. The high molybdenum and chromium content in Hastelloy C22 C2000 B2 B3 Rod Wire enhances resistance to localized corrosion. Their superior metallurgical stability ensures reliable performance under fluctuating temperature and pressure conditions.
The Hastelloy C22 C2000 B2 B3 Rod Wire range provides specialized performance for different environments. Hastelloy C22 offers outstanding resistance to oxidizing agents, while C2000 provides superior resistance to both oxidizing and reducing chemicals. Hastelloy B2 and B3, on the other hand, are particularly resistant to hydrochloric acid and other strong reducing agents. This combination of grades gives industries flexibility to select the right alloy for their specific applications. Hastelloy C22 C2000 B2 B3 Rod Wire ensures optimal protection and longevity in corrosive systems.
Hastelloy C22 C2000 B2 B3 Rod Wire is preferred in applications where maximum corrosion resistance is required, such as flue gas scrubbers and marine heat exchangers. They exhibit high mechanical strength, making them suitable for heavy-duty and high-pressure environments. The smooth surface finish of these rods and wires allows easy installation and precision assembly. Hastelloy C22 C2000 B2 B3 Rod Wire resists deformation under stress, maintaining dimensional accuracy. These alloys perform exceptionally well in both oxidizing and reducing atmospheres.
The manufacturing process of Hastelloy C22 C2000 B2 B3 Rod Wire ensures excellent uniformity, surface quality, and mechanical performance. They can be cold-drawn or annealed to meet specific industrial requirements. These rods and wires are widely used in the production of fasteners, springs, welding electrodes, and instrumentation components. The versatility of Hastelloy C22 C2000 B2 B3 Rod Wire makes them an essential choice for engineers and fabricators. Their long-term reliability and resistance to chemical attack guarantee superior performance in demanding operations.
In conclusion, Hastelloy C22 C2000 B2 B3 Rod Wire complies with international standards such as ASTM B574 and ASTM B622. They are available in various diameters, lengths, and finishes to suit diverse industrial needs. Hastelloy C22 C2000 B2 B3 Rod Wire provides a unique balance of strength, corrosion resistance, and workability. Their adaptability to multiple industrial environments ensures consistent performance and low maintenance. Choosing Hastelloy C22 C2000 B2 B3 Rod Wire is a cost-effective solution for achieving high-quality, long-lasting results in corrosive applications.
Specification Table
| Material | Standard | UNS Number | Form | Diameter Range | Condition | Finish |
|---|---|---|---|---|---|---|
| Hastelloy C22 | ASTM B574 / ASME SB574 | N06022 | Rod / Wire | 0.25 mm – 100 mm | Annealed / Cold Drawn | Bright, Polished, Black |
| Hastelloy C2000 | ASTM B574 / ASME SB574 | N06200 | Rod / Wire | 0.25 mm – 100 mm | Annealed / Cold Drawn | Bright, Polished, Black |
| Hastelloy B2 | ASTM B335 / ASME SB335 | N10665 | Rod / Wire | 0.25 mm – 100 mm | Annealed / Cold Drawn | Bright, Polished, Black |
| Hastelloy B3 | ASTM B335 / ASME SB335 | N10675 | Rod / Wire | 0.25 mm – 100 mm | Annealed / Cold Drawn | Bright, Polished, Black |
Chemical Composition (Typical ranges for SSC22 C2000 B2 B3)
Note: Values are typical ranges. Final composition will be confirmed on MTC provided per lot.
| Element | Hastelloy C22 (%) | Hastelloy C2000 (%) | Hastelloy B2 (%) | Hastelloy B3 (%) |
|---|---|---|---|---|
| Nickel (Ni) | Balance | Balance | Balance | Balance |
| Chromium (Cr) | 20.0 – 22.5 | 22.0 – 24.0 | ≤ 1.0 | ≤ 1.5 |
| Molybdenum (Mo) | 12.5 – 14.5 | 15.0 – 17.0 | 26.0 – 30.0 | 27.0 – 32.0 |
| Iron (Fe) | 2.0 – 6.0 | 2.0 – 6.0 | 2.0 max | 1.5 max |
| Tungsten (W) | 2.5 – 3.5 | 2.0 – 3.0 | – | – |
| Cobalt (Co) | 2.5 max | 2.0 max | 2.0 max | 2.0 max |
| Copper (Cu) | 0.5 max | 1.3 – 1.9 | 0.5 max | 0.5 max |
| Manganese (Mn) | 0.5 max | 0.5 max | 1.0 max | 0.5 max |
| Silicon (Si) | 0.08 max | 0.08 max | 0.1 max | 0.1 max |
| Carbon (C) | 0.015 max | 0.01 max | 0.02 max | 0.01 max |
| Phosphorus (P) | 0.02 max | 0.02 max | 0.04 max | 0.02 max |
| Sulfur (S) | 0.02 max | 0.02 max | 0.03 max | 0.02 max |
Mechanical Properties (Typical)
| Property | Hastelloy C22 | Hastelloy C2000 | Hastelloy B2 | Hastelloy B3 | Test Standard |
|---|---|---|---|---|---|
| Tensile Strength (MPa) | 760 min | 760 min | 760 min | 760 min | ASTM E8 / ASME SB |
| Yield Strength 0.2% (MPa) | 350 min | 350 min | 310 min | 310 min | ASTM E8 / ASME SB |
| Elongation (%) | 45 min | 45 min | 40 min | 40 min | ASTM E8 / ASME SB |
| Hardness (Rockwell B) | 90 max | 90 max | 85 max | 85 max | ASTM E18 |
| Density (g/cm³) | 8.69 | 8.62 | 9.24 | 9.22 | ASTM B962 |
| Melting Range (°C) | 1325 – 1370 | 1350 – 1390 | 1330 – 1380 | 1350 – 1400 | – |
Equivalent C22 C2000 B2 B3s
| Grade | UNS Number | Werkstoff Nr. | EN / DIN | AFNOR | JIS |
|---|---|---|---|---|---|
| Hastelloy C22 | N06022 | 2.4602 | NiCr21Mo14W | NC22DNW | NW 6022 |
| Hastelloy C2000 | N06200 | 2.4675 | NiCr23Mo16Cu | NC23D | – |
| Hastelloy B2 | N10665 | 2.4617 | NiMo28 | – | NW 0665 |
| Hastelloy B3 | N10675 | 2.4600 | NiMo29 | – | – |
Dimension & Weight Chart (Selected common sizes)
Below is a representative chart showing outside diameter, wall thickness, inside diameter, cross-sectional area of metal and calculated weight per metre (kg/m). Values are calculated using density = 7.93 g/cm³ and are for guidance — use actual MTC values for procurement & engineering.
| Diameter (mm) | Approx. Weight (kg/m) | Cross Sectional Area (mm²) | Tolerance (mm) | Available Form |
|---|---|---|---|---|
| 1.0 | 0.0068 | 0.785 | ±0.02 | Wire / Coil |
| 2.0 | 0.027 | 3.142 | ±0.03 | Wire / Coil |
| 3.0 | 0.061 | 7.069 | ±0.04 | Wire / Rod |
| 4.0 | 0.109 | 12.566 | ±0.05 | Rod |
| 5.0 | 0.170 | 19.635 | ±0.05 | Rod |
| 6.0 | 0.245 | 28.274 | ±0.06 | Rod |
| 8.0 | 0.435 | 50.265 | ±0.08 | Rod |
| 10.0 | 0.680 | 78.540 | ±0.10 | Rod |
| 12.0 | 0.978 | 113.097 | ±0.12 | Rod |
| 16.0 | 1.740 | 201.062 | ±0.16 | Rod |
| 20.0 | 2.720 | 314.159 | ±0.20 | Rod |
| 25.0 | 4.250 | 490.873 | ±0.25 | Rod |
Types Of Hastelloy C22 C2000 B2 B3 Rod Wires and Tubes
Stainless Steel Rod Wire
Monel 400 Rod Wire
Hastelloy Rod Wire
Inconel 600 Rod Wire
Nickel Rod Wire
Super Duplex Rod Wire
Duplex Rod Wire
Monel K500 Rod Wire
Frequently Asked Questions (FAQ)
What are Hastelloy C22, C2000, B2, and B3 Rod & Wire used for?
Hastelloy C22, C2000, B2, and B3 Rod & Wire are primarily used in chemical processing, petrochemical, marine, and aerospace industries. They are ideal for equipment exposed to aggressive chemicals, acids, and high-temperature environments such as reactors, heat exchangers, and piping systems.
What is the main difference between Hastelloy C22, C2000, B2, and B3?
Hastelloy C22 offers outstanding resistance to oxidizing and reducing chemicals, while C2000 provides added protection against oxidizing media due to its copper content. B2 and B3 are optimized for resistance to strong reducing agents like hydrochloric acid, with B3 offering improved thermal stability over B2.
Are Hastelloy Rods and Wires suitable for welding and fabrication?
Yes, Hastelloy Rods and Wires have excellent weldability and formability. They can be easily fabricated using conventional methods such as TIG, MIG, and resistance welding, ensuring high structural integrity in demanding applications.
What standards govern Hastelloy C22, C2000, B2, and B3 Rod & Wire?
These materials are produced in accordance with international standards including ASTM B574, ASTM B335, and ASME SB specifications. Each grade conforms to stringent mechanical, chemical, and dimensional requirements.
What surface finishes are available for Hastelloy Rod & Wire?
Common finishes include bright, polished, and black. These finishes enhance appearance and corrosion resistance, depending on the intended application. Bright and polished finishes are often used in precision and high-purity systems.
