Inconel 625 Sheet, Plate & Coil is a high-performance nickel-chromium alloy known for its excellent resistance to oxidation and corrosion. It is widely used in industrial applications where high temperature and corrosive environments are common, such as chemical processing, aerospace, and power generation.
The alloy’s superior mechanical properties, including high tensile strength and durability, make Inconel 625 an ideal choice for manufacturing sheets, plates, and coils. These forms are versatile and can be easily fabricated into components for various industrial applications.
Inconel 625 Sheets are available in different thicknesses and dimensions, making them suitable for custom applications. They are commonly used in heat exchangers, furnace components, and chemical reactors due to their exceptional thermal stability.
Inconel 625 Plates offer excellent resistance to high-temperature corrosion and are often used in flanges, pressure vessels, and structural components in chemical and petrochemical industries. Their high strength at elevated temperatures ensures long-lasting performance.
Inconel 625 Coils are widely utilized in applications requiring continuous processing or forming, such as in industrial equipment and heat treatment systems. Coils can be cut, rolled, and formed into custom parts as per engineering requirements.
The chemical composition of Inconel 625 includes nickel, chromium, and iron, which contribute to its outstanding corrosion resistance and mechanical strength. The alloy maintains stability in both oxidizing and reducing environments, including acidic and alkaline solutions.
Inconel 625 is highly resistant to scaling and oxidation, even at temperatures up to 1200°F (650°C). This property makes it suitable for use in high-temperature furnace components, combustion chambers, and aerospace engine parts.
Fabrication of Inconel 625 Sheets, Plates, and Coils can be done using standard techniques such as welding, machining, and forming. Proper handling and heat treatment ensure optimal performance and longevity of the alloy components.
Specification Table
| Property | Unit | Inconel 625 Sheet / Plate / Coil |
|---|---|---|
| Alloy Type | - | Nickel-Chromium-Molybdenum Alloy |
| Standards | - | ASTM B443, AMS 5662, UNS N06625 |
| Form | - | Sheet, Plate, Coil |
| Thickness | mm | 0.5 – 200 |
| Width | mm | 1000 – 2500 |
| Length | mm | 1000 – 6000 (custom lengths available) |
| Finish | - | Hot Rolled, Cold Rolled, Mill Finish |
| Surface Treatment | - | Polished / Annealed |
| Certification | - | ISO 9001, EN 10204 3.1/3.2 |
Chemical Composition (Typical ranges for SSSheet)
Note: Values are typical ranges. Final composition will be confirmed on MTC provided per lot.
| Element | Composition (wt%) |
|---|---|
| Nickel (Ni) | 58.0 – 63.0 |
| Chromium (Cr) | 20.0 – 23.0 |
| Molybdenum (Mo) | 8.0 – 10.0 |
| Iron (Fe) | 5.0 max |
| Cobalt (Co) | 1.0 max |
| Manganese (Mn) | 0.5 max |
| Silicon (Si) | 0.5 max |
| Carbon (C) | 0.1 max |
| Phosphorus (P) | 0.015 max |
| Sulfur (S) | 0.015 max |
| Niobium + Tantalum (Nb + Ta) | 3.15 – 4.15 |
Mechanical Properties (Typical)
| Property | Value | Unit |
|---|---|---|
| Density | 8.44 | g/cm³ |
| Tensile Strength | 690 – 830 | MPa |
| Yield Strength (0.2% offset) | 275 – 400 | MPa |
| Elongation at Break | 30 – 50 | % |
| Hardness (Rockwell B) | 80 – 95 | HRB |
| Modulus of Elasticity | 207 | GPa |
| Poisson's Ratio | 0.31 | - |
| Melting Point | 1290 – 1350 | °C |
| Max Service Temperature | 980 | °C |
Equivalent Grades
| Standard | Equivalent Grade |
|---|---|
| ASTM / ASME | SB-443, B443 |
| UNS | N06625 |
| EN / DIN | 2.4856 |
| JIS | SN06625 |
| Nickel Alloy Reference | Alloy 625 |
Dimension & Weight Chart (Selected common sizes)
Below is a representative chart showing outside diameter, wall thickness, inside diameter, cross-sectional area of metal and calculated weight per metre (kg/m). Values are calculated using density = 7.93 g/cm³ and are for guidance — use actual MTC values for procurement & engineering.
| Thickness (mm) | Width (mm) | Length (mm) | Weight per Sheet (kg) |
|---|---|---|---|
| 1 | 1000 | 2000 | 16.88 |
| 2 | 1000 | 2000 | 33.76 |
| 3 | 1250 | 2500 | 79.31 |
| 5 | 1500 | 3000 | 189.9 |
| 6 | 1500 | 3000 | 227.9 |
| 10 | 2000 | 6000 | 1012.8 |
Common Types Of Sheets
Shim Sheet
Perforated Sheet
Chequered Plate
Coil
Strips
Foil
Hot Rolled Sheets
Cold Rolled Plate
Matt PVC Sheet
Frequently Asked Questions (FAQ)
What is Inconel 625?
Inconel 625 is a nickel-chromium-molybdenum alloy known for its excellent corrosion resistance, high strength, and durability at elevated temperatures. It is widely used in aerospace, chemical, and marine industries.
What forms are available for Inconel 625?
Inconel 625 is available in Sheet, Plate, and Coil forms with various thicknesses, widths, and lengths.
What are the key applications of Inconel 625?
It is used in chemical processing equipment, marine components, aerospace parts, power generation, and oil & gas industries due to its excellent corrosion and oxidation resistance.
What standards does Inconel 625 conform to?
Common standards include ASTM B443, AMS 5662, and UNS N06625.
What is the maximum service temperature of Inconel 625?
Inconel 625 can be used continuously at temperatures up to 980°C (1800°F) in oxidizing and corrosive environments.
